The TP-Link Omada ES224G V1.6 switch delivers reliable and efficient network performance with 24 ports offering speeds of 10/100/1000 Base-T. Capable of supporting up to 4000 VLANs and 32 priority queues, this switch is ideal for managing large networks. With a robust MTBF of over 400,000 hours, it is designed for continuous operation in various environments, maintaining functionality within a temperature range of -5°C to 50°C. Further enhancing its usability, the device supports features such as IGMP snooping, VLAN support, and Quality of Service (QoS) capabilities to optimize network traffic. Coupled with cloud management and a fanless design, this switch provides a quiet solution for data handling in any setting.

Please note

TP-Link Easy Managed switches do not collect client IP information and thus do not report client IPs to the controller.

Key Selling Points

Supports up to 4000 VLANs and 32 priority queues
Robust MTBF of 400,770 hours for dependable performance
Fanless design for silent operation
Compliant with multiple standards for broad compatibility
Includes a rack mounting kit for flexible installation

Product Features

With a switching capacity of 48 Gbps and a packet forwarding rate of 35.7 Mpps, the switch is engineered to handle demanding network traffic efficiently.

Designed to operate in temperatures ranging from -5°C to 50°C and capable of storage in conditions as low as -40°C, this switch is built for various operational environments.

With features like flow control, port mirroring, and VLAN tagging, the switch manages network packets effectively, providing enhanced performance and stability.

This switch includes mechanisms for Broadcast, Multicast, and Unicast Storm Control, ensuring uninterrupted network service during heavy traffic spikes.

Equipped with 6 kV Surge protection and ESD Protectors for both contact and air-gap discharges, this switch offers enhanced reliability against electrical surges.

Attributes

Main Specifications

Capacity

Priority queues: 8VLAN groups: 32VLANs supported: 4000

Compliant Standards

IEEE 802.1p, IEEE 802.3x, IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u

Device Type

Switch - 24 ports - managed

Dimensions (WxDxH)

29.4 cm x 14 cm x 4.4 cm

Enclosure Type

Rack-mountable

Features

Reset button, cloud managed, VLAN support, port isolation, Cable Diagnostics Function, QoS, loop prevention, IGMP snooping, fanless, metal housing, traffic prioritization, ZTP, security lock slot (cable lock sold separately), auto-negotiation, auto-uplink

Jumbo Frame Support

15KB

MAC Address Table Size

8K entries

Performance

Switching capacity: 48 GbpsPacket forwarding rate: 35.7 MppsPacket buffer size: 4 Mbit

Ports

24 x 10/100/1000Base-T

Power

AC 100-240 V (50/60 Hz) 0.6 A

Product Description

TP-Link Omada ES224G V1.6 - switch - 24 ports - managed - rack-mountable

Remote Management Protocol

DHCP

Routing Protocol

IGMP, IGMPv2, IGMPv3

Subtype

Gigabit Ethernet

TP-Link ES224G - Omada 24-Port Gigabit Easy Managed Switch

Name: TP-Link ES224G - Omada 24-Port Gigabit Easy Managed Switch
Brand: TP-Link
SKU: PLE-673717
Price: 169.00 AUD
Availability: InStock

169

VIC :

VIC Warehouse

In Stock

WA :

Bentley

In Stock

Cockburn

Approx 1 business day

Osborne Park

In Stock

WA Warehouse

Approx 1 business day

Wangara

Approx 1 business day

Set your location for shipping prices

Set

PLE Code

PLE-673717

Manufacturer

TP-Link

Boxed Weight

1.89

Model Number

ES224G

Warranty

3 Year PLE Standard Return to Base

Buy now, pay later.

Same day delivery*

A large marketing image providing additional information about the product TP-Link ES224G - Omada 24-Port Gigabit Easy Managed Switch - Additional alt info not provided

This document and other documents provided pursuant are for informational purposes only. The information type should not be interpreted to be a commitment on the part of the Supplier. The Supplier cannot guarantee the accuracy of information presented. The user assumes the entire risk as to the accuracy and the use of this document. This document may include screenshots from the manufacturer's website which may be used for multiple variations of this product. The model number supplied at the top of this page (explicitly specified as "Model Number") is the exact model item you will receive.
